Specifications:
- LF transducer: 6.5 in (165 mm) dual voice coil weather treated paper cone woofer
- Effective frequency range 45 Hz – 150 Hz
- Rated noise power / voltage 100 W / 20 V (rms)
- Sensitivity [dB] (rated @1 W, 1 m) 86
- Maximum SPL [dB] (continuous / peak) 100 / 106
- Recommended amplifier 100 W
- Transformer taps / impedance 100 V: 100, 50, 25 W (mono only) Bypass: 4 Ω mono or 8 Ω + 8 Ω stereo
- Connectors Hi-Z mono input: 4-pole Euroblock with thru output Low-Z input: 4-pole Euroblock, left (mono) and right Hi-pass output: x2 4-Pole Euroblock for x4 satellites
- Enclosure material Vinyl wrapped medium density fiberboard
- Port baffle / cover panel ABS
- Operating environment Designed for indoor use
- Net weight 10.7 kg
- Product dimensions (H x W x D) 350 x 209 x 432 mm
